Product Details
＋
Specifications
Please note - specifications subject to change without prior notice.
| FRAME | ONE-FORTY LITE III; 143 STR 29"; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
| SHOCK | Marzocchi Bomber inline |
| FORK | Marzocchi Z2; Air; 150 STR; Tapered; 44mm fork offset; 29.5x2.6" max. WHS |
| BRAKE-F | Tektro Gemini M535; 4 piston |
| BRAKE-R | Tektro Gemini M535; 4 piston |
| ROTOR-F | Tektro TR203-45; 203mm |
| ROTOR-R | Tektro TR203-45; 203mm |
| CHAIN | KMC xGlide |
| CHAINGUARD | |
| CRANKSET | MERIDA Expert TR II; 32 ATC |
| CRANK LENGTH | 170 mm for all sizes |
| BOTTOM BRACKET | Samox BSA 24mm EB2401 |
| DERAILLEUR-FRONT | |
| DERAILLEUR-REAR | Shimano CUES U6000; GS |
| CASSETTE | Shimano LG400; 11-50 ATC; 11 GER |
| GRIPS | MERIDA COMP EC |
| HANDLEBAR | MERIDA EXPERT TR II; MAT aluminium; 780 WHB; XS/S 18 RHB; M/L/XL 30 RHB |
| STEM | MERIDA EXPERT eTRII; MAT aluminium; 35 DSH; 0 ASD |
| STEM SIZE | 40 mm |
| HEADSET | Acros ICR MERIDA EXTERNAL neck; Upper and lower IPS sealing |
| HUB-F | Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
| HUB-R | Shimano TC500-HM-B; 148x12 WHR; 32 SPH; Centerlock |
| AXLE-F | |
| AXLE-R | MERIDA COMP TR; including removeable lever, 6/4mm allen key |
| RIM | MERIDA COMP TR II; 110x15 WHF; 148x12 WHR; 28 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included); 29" |
| SADDLE | MERIDA COMP SL; 25% recycled material; V-mount; incl. MERIDA minitool |
| SEAT CLAMP | MERIDA EXPERT |
| SEATPOST | MERIDA EXPERT TR II; 34.9 DSP; 0 SSB; XSHORT/SHORT: 150 SPT - MID: 170 SPT - LONG: 200 SPT - XLONG: 230 SPT |
| SHIFTER-FRONT | |
| SHIFTER-REAR | Shimano CUES U6000 |
| SPOKES | Black stainless |
| TIRE-F | Kenda Regolith; 29x2.4"; wire |
| TIRE-R | Kenda Regolith; 29x2.4"; wire |
